 >> Home > CUSTOMIZE > I36DUA-UMW











I36DUA model design combines peak performance and near silent operation.

You should really experience it; creating a perfect flow over the motherboard.

the 92*92*38 mm fan is PMW controlled and the speed can vary between 1000

to 3000 rmp creating a noise-output of an inaudible 21 dB(A) up till a still truly

quiet 38 dB(A).

Main Features:

Intel® Core™ i7 Processor Extreme Edition

Intel® Core™ i7 Processor





Description Socket Type Intel I366 Socket
Cooler dimension 131.5 * 131.5 * 84.5 mm
Fan Spec Dimension 92*92*38 mm
Bearing type Two Ball bearing/ one ball one sleeve bearing/ EBR bearing
Rotational Speed 1000~2800 rpm +200/-300rpm (PWM)
Acoustic level 21~37 dB(A)
Life 60000 hrs/ 50000 hrs/ 40,000 hrs
Airflow 23~64 CFM
Voltage DC 12V
Thermal  Interface  Material High performance thermal grease
Application

Intel® Core™ i7 Processor Extreme Edition

Intel® Core™ i7 Processor

Remark According to customer’s system thermal and acoustic level requirement, ThermalFly can depends on request to make customization model.Push pin and screw spring fastener available.
