 >> Home > RETAIL PRODUCT > I36DUA-PHW









I36DUA model design combines peak performance and near silent operation.

You should really experience it; creating a perfect flow over the motherboard.

Main Features:

Intel® Core™ i7 Processor Extreme Edition

Intel® Core™ i7 Processor





Description Socket Type Intel I366 Socket
Cooler dimension 131.5 * 131.5 * 71.5 mm
Fan Spec Dimension 90*90*25 mm(R)
Bearing type Two Ball bearing/ one ball one sleeve bearing/ EBR bearing
Rotational Speed 1200~3600 rpm ± 300rpm (PWM)
Acoustic level 19~38 dB(A)
Life 60000 hrs/ 50000 hrs/ 40,000 hrs
Airflow 14~43 CFM
Voltage DC 12V
Thermal  Interface  Material High performance thermal grease
Application

Intel® Core™ i7 Processor Extreme Edition

Intel® Core™ i7 Processor

Remark According to customer’s system thermal and acoustic level requirement, ThermalFly can depends on request to make customization model.Push pin and screw spring fastener available.
