High thermal conduction and low noise design





Excellent ratio aluminum extrusion heatsink for better heat dissipation and silent operation. Silent solution that special reversed fan reducing the noise for AMD Phenom™ X4 Quad-Core (95W) processor.




Description Socket Type AMD 754/ 939/ 940/ AM2/ AM2+/AM3/ AM3+/ FM1/ Socket F compatible
Cooler dimension 80.6 * 80.6 * 61.5 mm
Fan Spec Dimension 80 * 80 * 25 mm
Bearing type Two Ball bearing/ one ball one sleeve bearing/ EBR bearing
Rotational Speed 2600 rpm ±10% (3Pin)
Acoustic level 30 dB(A)
Life 60000 hrs/ 50000 hrs/ 40,000 hrs
Airflow 39.8 CFM
Voltage DC 12V
Thermal  Interface  Material High performance thermal grease

AMD Phenom™ X4 Quad-Core (95W)

AMD Phenom™ II X4 (95W)

AMD Phenom™ X3 Triple-Core

AMD Phenom™ II X3 (95W)

AMD Business Class- AMD Phenom™ X4 Quad-Core Processors (95W)

AMD Business Class- AMD Phenom™ X3 Triple-Core Processors

AMD Athlon™

AMD Athlon™ FX (89W)

AMD Athlon™ X2 Dual-Core (95W)

AMD Business Class- AMD Athlon™ X2 Dual-Core Processors

AMD Business Class- AMD Athlon™ Processors

AMD Sempron™

Remark According to customer’s system thermal and acoustic level requirement, ThermalFly can depends on request to make customization model.
