| Description |
Socket Type |
Intel LGA1156/ LGA1155 Socket |
| Cooler dimension |
124 * 124 * 61.5 mm |
| Fan Spec |
Dimension |
90 * 90 * 25 mm |
| Bearing type |
Two Ball bearing/ one ball one sleeve bearing/ EBR bearing |
| Rotational Speed |
900~2300 rpm ±10% (PWM) |
| Acoustic level |
20~29 dB(A) |
| Life |
60000 hrs/ 50000 hrs/ 40,000 hrs |
| Airflow |
15~38 CFM |
| Voltage |
DC 12V |
| Thermal Interface Material |
High performance thermal grease |
| Application |
Intel® Core™ i5 Processor all series |
| Remark |
According to customer’s system thermal and acoustic level requirement, ThermalFly can depends on request to make customization model.Push pin and screw spring fastener available.
|
